About GATERON EF Curry Linear Switch
Gateron's EF Curry Linear Switch, part of their EverFree sub-brand, is a low-volume linear switch made using brand-new molds and advanced manufacturing techniques, reducing costs while maintaining high quality. These switches feature a smooth linear travel from top to bottom and come pre-lubed from the factory for added smoothness. Made with proprietary Gateron materials, they are designed to be relatively quiet, thanks to unique housing materials. The switch is compatible with any PCB that supports Cherry-style switches, with 5 pins that can be modified to 3 by clipping off the extra 2 pins if necessary.
The EF Curry switch also features a 15mm double-stage spring, providing a bouncy and responsive typing experience. With a 60g bottom-out force, it offers a well-balanced feel for linear switch enthusiasts. Since these switches are already pre-lubed and low-volume out of the box, additional lubing is optional. However, if desired, a thin lube like Carbon GS1 or Tribosys 3203 is recommended to maintain optimal performance without compromising their smoothness. Sold in packs of 18, these switches are an excellent choice for those seeking a high-quality, affordable linear switch with a soft and quiet feel.
EF Curry Linear
• Type: Linear
• Operating Force:50+10gf
• Pre Travel:2.0+0.5mm
• Total Travel:4mm Max
• Stem:POM
• Top Housing: PC
• Bottom Housing: Nylon
• LED Support: SMD
• Pre-Lubed: Yes
• Spring:15mm
• Pins:5-Pin
